Cooking zones

Operation

Features

Two zones, each 1500 W, can be operated together as a complete surface or each halve separately.
Keeping warm setting.
Cleaning setting.
Simple to clean surface.

Safety

Planning notes

Depending on the type of installation - surface-/ or flush-mounted, with or without cover - the specific location of the control knob positions may vary.
If combining several Vario appliances of the 400 series, a connection strip VA 420 must be placed between the appliances. Depending on the type of installation, the corresponding connection strip must be provided.
The bearing capacity and stability,
in the case of thin countertops in
particular, must be supported using
suitable substructures. Take into
account the appliance weight and
additional loads.
Additional instructions for flush mounting:
Flush installation is possible in countertops made of stone, synthetics or solid wood. Heat resistance and watertight sealing of the edges must be observed. For other materials, please consult with your countertop manufacturer.
The groove must be continuous and even, so that uniform placing of the appliance on the gasket is ensured. Do not use discontinuous lining.
The joint width may vary due to size tolerances of the combinations and of the countertop cut-out.
If installing several appliances in individual cut-outs allow for a division bar of inimum 1 " (50 mm) between the individual cut-outs.
A minimum lateral clearance of at least 40 mm from adjacent heat-sensitive furniture or contact surfaces must be observed or thermal insulation fitted.
Appliance can be snapped into the worktop from above.
Appliance weight: approx. 12 kg.

Rating

Hard chrome-plated surface for teppan cooking and use as griddle, grill, searer and warming plate. No pots or pans necessary.
Exact temperature control up to 480 (degree)F, with warming and cleaning settings
Optimum heat distribution
Solid stainless steel control knobs
Precision crafted 1/8-inch stainless steel frame

Gaggenau Accessories-VP414611

Package includes
